Service Life: Use the Digital Controller within the following temperature and humidity ranges:
Temperature: −10 to 55°C (with no icing or condensation), Humidity: 25% to 85%.
●The Control can be programmed with maximum 64 segments
☑ The system timing unit can be seconds,or minutes(Maximum 9999 minutes)
☑Can be execute from "0" or from any segment.
☑Can be execute automatically right after power on.
☑Can be exectue or terminated from front panel
☑Can be restored after power failure situation.
☑Can be configured to repeat itself after finish a program
☑Can be configured to STOP itself after finish a program
●Can be connect the following sensors and signals to the universal input(K.E,J.T.S,R,B,N,PT100).
●Can be easily set the optimum PID constants by performing AT (auto-tuning) with the limit cycle method,or ON-OFF Control Mode.
●With any model that supports communications, you can use communications , Modbus-RTU
●With any model that provides a transfer process value as a 4 to 20 mA or 1 to 5 V transfer output.
